Euromac BX Plus Autoindex 1250/30-1300
BX — a coordinate punching machine with the AutoIndex automatic tool rotation system sets a new standard in CNC machining.
The new enlarged frame enables the machine to operate at higher speeds.
This design feature ensures exceptional stability and accuracy, guaranteeing flawless quality when punching holes in sheet metal.
| Max. punching force (kN) | 300 |
| Y axis with Multitool /Monoounch (mm) | |
| Y = 1000 | 1050 |
| Y = 1250 | |
| Positioning accuracy (mm) | +/- 0.05 |
| Opening of clamps (mm) - standard | 11 |
| Max. hit rate (1/min): | |
| Punching with 20 mm pitch | 250 |
| Nibbling with 1 mm pitch | 550 |
| Thickness range (mm) | 0.6-11 |
| Max. thickness (mm) with standard clamps | 11 |
| Max. thickness (mm) with op. clamps 13 mm (for copper / aluminium) | 12.5 |
| Max. weight at reduced axis speed (kg) | 150* |
| USB port | 6 |
| Installed power (kW) | 8.5 |
| Approx, weight (kg) | |
| X = 2250 | 7900 |
| X = 2500 | 8500 |
| Overall dimensions (mm) | |
| X = 2250 | 3980 x 3630 |
| X = 2500 | 4850 x 3630 |
| * for sheets of over 50 kg weight combined brush and balls tables are required | |
